PERGOLUX Fan

Your pergola, now with Integrated breeze.

  • SnapFIT™ mounting clicks directly into your pergola in minutes
  • Cools your entire seating area with a steady breeze over a range of up to 4.5 meters
  • Whisper-quiet brushless motor with a lifespan of over 10,000 hours
  • Controllable via the PERGOLUX app, smart home or your remote control
  • Weatherproof and IP65 certified, built for outdoor use all year round
Show Less
Show More
Colour.
Anthracite circle
white-icon
Your order

Your order
Availability
Availability
${ selectedVariant.variantTitle || selectedVariant.title }$
${ variant.variantTitle || variant.title }$
${ getStockLevelText(variant) }$

Something went wrong while processing your request. Please try again or contact our support team for assistance.
Technical Specs
Fans Product Specification

Dimensions & Installation

Fan diameter 340 mm (13.4 inches)
Fan depth (case) 260 mm (10.2 inches)
Protruding beam during installation 0 mm – Fully Flat (SnapFIT Models)
Mounting bracket dimensions 90 × 90 mm (3.5 × 3.5 inches)
Cable length (double laying) 3,000 mm + 3,000 mm (3.0 m + 3.0 m)
Net weight 1.6 kg
Packaging (L × W × H) 395 × 375 × 335 mm
Units per outer carton 1
Required fastening material SnapFIT included
Required mounting hardware (screw-mounted models) 2× self-tapping screws, not included
Estimated installation time Approx. 5 minutes

Electrical Connection

Engine type Brushless DC Motor (BLDC)
Nominal voltage 120–240 V AC (universal – for all Pergolux markets)
Frequency 50 / 60 Hz
Nominal/maximum power consumption 20 W (0.027 hp)
Current consumption 0.3 A
Consumption in standby mode 0.48 W
Overload protection Yes

Performance

Speed control Stepless, up to 1,280 rpm
Speed range 425–1,280 rpm
Air velocity 4 m/s
Effective cooling range 4.5 m – covered (in a protected environment)
Cooling area ~3 m² – directly under the fan
Noise level 40–60 dB(A)
Maximum continuous service life 8 hours
Engine life 10,000 hours
Bearing type Bearings

Warranty

Warranty 2 years
